| Brand Name: | KINCOTO |
| Model Number: | KU8000A |
| MOQ: | 1 pcs |
| Price: | 25000USD/PCS |
| Payment Terms: | T/T |
| Supply Ability: | 10000 |
1.The feeding area can stack 50 tubes containing chips, and feed materials can be added at will without affecting production.
2.Golden finger contact programming, lifespan can reach 3 million times.
3.When the programming is completed, OK and NG materials are automatically distinguished and placed in the OK tube or NG tube accordingly.
4.Support programmer: offline programmer (self-made programmer, SFLY, Holtek, Sonix, ELAN, Nyquest,PADAUK, Hyundai, SinoWealth, Airoha Technology, JIELI Technology, Buildwin, CT-UNITE, NATiON....)
5.Equipped with AOI visual inspection, accurately detect IC direction and appearance.
6.High stability and low failure rate, suitable for long-term continuous production.
7.Compact structure and stable performance, seamlessly compatible with automated production lines to meet the demands of large-scale and high-efficiency electronic manufacturing.
8.Dual inspection + automatic sorting mechanism effectively prevents defective products from entering the next process, improving overall product quality.
It can accommodate four programming sockets (the size of the programming sockets depends on the chip size). When replacing chips with different packages, for chips of the same brand, only the socket size needs to be changed. For different brands, only the programmer and programming socket need to be changed, which is simple and convenient.
A dot function can be added when the tape is woven out.(Red, blue, yellow, green, orange)
Parameter
| Output efficiency | 8000UPH |
|---|---|
| Host size | 1700*1300*1760mm |
| Supports ic packaging | SOP150/SSOP150/SOP210/MSOP8...... |
| Programming station | 4 stations(golden finger) |
| Air humidity | 20-95%(no condensation) |
| Feeding mode | Automatic feeding,can put 50 tubes |
| Receiving method | Automatic feeding,can put 50 tubes |
| Pick and place accuracy | 0.05mm |
| Programming mode | PLC |
| Test fixture | Golden finger,lives about 3 million times |
| Input voltage | AC220V/50 HZ |
| Air source | 0.4-0.6MPA |
| Power | 0.4KW |
| Total weight | 190KG |
